Color-coded forming die components and rollers

Pipe Bender Accessory, 028 Die Package Tooling, without Program Cards (Huth: model 028)

$4,264.20

SKU: HUT-028 Category: Brand:

Description

This post contains affiliate links.

Huth 028 Die Package Tooling

Radius Dies

No. Radius Size
5530* 5″ 3″
5200* 5″ 2″
5414* 5″ 21⁄4“
5412* 5″ 21⁄2“
4200 4″ 2″
4414 4″ 21⁄4“
3112 3″ 11⁄2“
3134 3″ 13⁄4“
*Requires 41041 retainer

Swage Dies

No. Size
112 11⁄2“
134 13⁄4“
** For a 2″ ID Use
Male Ball Tool 550
*** For a 21⁄4” ID Use Male Ball Tool 552
**** For a 21⁄2” ID Use Male Ball Tool 553
***** For a 23⁄4” ID Use Male Ball Tool 554

Arbor

No. Size
572 1 3/8″ to  1 3/4″ One Piece
573 1 3/4″ to 4″ One Piece

Back Shoes

No. Pcs. Size
1112 2 11⁄2“
1134 2 13⁄4“
1200 2 2″
4211 2 21⁄4“
4412 2 21⁄2“
1350 2 3″

Collet Sets

No. Size
1712 11⁄2“
1734 13⁄4“
1720 2″
1725 21⁄4“
1750 21⁄2“

Segment Sets

No. Size
472 11⁄2” to 13⁄4” Solid Surface
474 13⁄4” to 21⁄8“
475 21⁄8” to 21⁄2“
476 21⁄2” to 3″

Half Shoes

No. Size
1038 11⁄2“
1040 13⁄4“
1045 2″
4416 21⁄4“
4410 21⁄2“

Ball Joint Tooling

No. Size
550 13⁄4” Male**
552 2″ Male***
553 21⁄4” Male****
554 21⁄2“Male*****
555 13⁄4” to 2″ Female
 556  21⁄4” to 21⁄2” Female

Accessories

No. Description
853 11⁄2” to 31⁄2” Flaring/Flanging Tool
855 Die pins (30)
815 Die Holder
870 Rubber O-Ring Assortment

Doming Dies

No. Size
557 21⁄2“
558 23⁄4“
